TF02 PRO LiDAR Rangefinder (40m)

The new TF02 Pro LiDAR from Benewake builds of the highly successful TF02 Increased range and performance now 40m

Benewake TF02 Pro (40m)

Description

Benewake TF02-Pro LIDAR LED Rangefinder IP65 Features a single-point ranging LiDAR Can achieve stable, accuracy, sensitive and high-frequency range detection Offers a sensor range up to 40 meters Has an ambient light resistance up to 100 Klux The Benewake TF02-Pro LIDAR LED Rangefinder IP65 (40m) is a single-point ranging LiDAR based on TF02 upgrade. The performance and accuracy of different reflectivity are improved, it can achieve stable, accuracy, sensitive and high frequency range detection. The protection design of the TF 02 is based on the IP65 level, which prevents it from the dust, water, and corrosion. It is anti-interferential from the strong light outdoors. It can work under 100K lux light without the interference from the temperature, humidity, light, electronics and airflow. Scan frequency up to 100 Hz, real-time detection of distance with a 100 times/second refresh rate for more accurate data. TF02 has a complete system, containing a protective shell made of materials with a high transmittance of infrared, which doesn't affect the optical performance. It has been widely used in height fixing and terrain following of drones, especially in agriculture.

Specifications

Product performance Operating Range: 0.05 ~40 m @90% reflectivity 0.05 ~13.5 m @10% reflectivity 0.05 ~40 m @90% reflectivity (100 Klux) 0.05 ~13.5 m @10% reflectivity (100 Klux)

Accuracy: ±5 cm (0.05 ~5 m), ±1% (5~40 m)

Distance Resolution: 1 cm

Frame rate: 100 Hz

Repeatability: 1σ: Other Parameters

Weight: 50 g (with cables)

Enclosure material: PC/ABS

Storage temperature: -30 ~80 °C

Cable length: 80 cm

What's Included/strong> 1 x Benewake TF02-Pro LIDAR LED Rangefinder IP65 (40m)
